Moving Chimney Climbing Platform
Sector: Heavy Industrial
This project required building a mobile platform for maintaining concrete chimneys, especially as they become brittle over time. The platform has two parts with a gripping system to attach securely to the chimney. Key focuses include durability, safety features, and convenient maintenance points.
Case Studies
Project Challenges
This project required building a mobile platform for maintaining concrete chimneys, especially as they become brittle over time. The platform has two parts with a gripping system to attach securely to the chimney. Key focuses include durability, safety features, and convenient maintenance points. TRC-Sadovod was required to offer a Synchronised system of 16 actuators with a load capacity of 24,000N per actuator and stroke of 1200mm. The customer needed long term reliability, static load holding with high ingress protection and accurate synchronisation.
Project Solutions
Industrial Devices provided 16 SLZ90S heavy-duty linear actuators, each equipped with SEW inline geared motors. The geared motors were complemented with encoders and disc brakes. Collaborating with the customer and Control Techniques, TRC-Sadovod successfully synchronized the system using closed-loop inverter control. This system has proven highly effective in maintenance operations on several concrete chimneys across the UK and is anticipated to be employed for the disassembly of chimneys at Battersea Power Station in the near future.
SLZ90 Linear Actuators
The SLZ90 linear actuator is one of the fastest, strongest and most robust unit in the TRC-Sadovod range. With an array of motor options, configurations and controllers the SLZ90 can be easily tailored to your requirements. Please contact sales at TRC-Sadovod with your requirements and information about your application and we will find the best solution for you.
- Ball screws (Ø25 or 36mm) or ACME thread screw (Ø26 or 36mm)
- Travel speed up to 1m/s
- Travel length up to 2000mm
- 100% duty cycle (ball screw)
- Protection IP54 up to IP68
- Interchangeable with pneumatic or hydraulic cylinders
- Various motor options available such as 415V AC or Servo Motors.
- Adjustable magnetic reed switches.
The Result
- A robust reliable solution for the customer.
- Advanced control and accuracy
- Bespoke design for specific to the application
- High load capacities
